Drawing our data in React
Next, we fill out our Line component for a flexible way to draw our data.
We already imported our Line
component from our chart library. Let's render one instance inside of our Chart
, passing it our data and scaled accessor functions.
xxxxxxxxxx
<Line
data={data}
xAccessor={xAccessorScaled}
yAccessor={yAccessorScaled}
/>
If we inspect our webpage in the Elements panel, we can see a new <path>
element.

Let's see what's going on in src/Chart/Line.jsx
.
We have a basic element that renders a <path>
element with a class name.
xxxxxxxxxx
const Line = ({ type, data, xAccessor, yAccessor, y0Accessor, interpolation, props }) => {
return (
<path {props}
className={`Line Line--type-${type}`}
/>
)
}
Line
accepts data
and accessor props, along with a type
string. A Line
can have a type
of "line"
or "area"
— it makes more sense to combine these two types of elements because they are more similar than they are different. There is one more prop (interpolation
), which we'll get back to later.
This lesson preview is part of the Fullstack D3 Masterclass course and can be unlocked immediately with a single-time purchase. Already have access to this course? Log in here.
