title: "CSS transitions"
description: "We learn about CSS transitions and the different CSS transition properties, then run through a concrete example and look at how to debug them."
useMdx: true
privateVideoUrl: https://fullstack.wistia.com/medias/bjxk1p47n5
codeFolder: course/module_03/lesson_03.01/protected/code/04-animations-and-transitions/end
---

# CSS transitions

<CodeSandboxEmbed
  src="//codesandbox.io/s/f79sh?fontsize=14&hidenavigation=1&theme=dark&autoresize=1&module=/chart.js"
  style={{width: '100%', height: '35em'}}
/>

Many of our chart changes can be transitioned with the CSS `transition` property. When we update a `<rect>` to have a fill of **red** instead of **blue**, we can specify that the color change take 10 seconds instead of being instantaneous. During those 10 seconds, the `<rect>` will continuously re-draw with intermediate colors on the way to **red**.

Let's try out an example! In our example, you'll see a blue box that moves and turns green on hover.

![box transition](https://d2uusema5elisf.cloudfront.net/courses/fullstack-d3-masterclass/module_03/lesson_03.01/public/images/4-animations-and-transitions/css-transition.png)

Let's open up the

`styles.css` file to take a look at what's going on. We can see our basic styles for the box.

```css
.box {
    background: cornflowerblue;
    height: 100px;
    width: 100px;
}
```

And our styles that apply to our box when it is hovered (change the background color and move it 30 pixels to the right).

```css
.box:hover {
    background: yellowgreen;
    transform: translateX(30px);
}
```

To create CSS a transition, we need to specify how long we want the animation to take with the `transition-duration` property. The property value accepts **time CSS data types** — a number followed by either `s` (seconds) or `ms` (milliseconds).

Let's make our box changes animate over one second.

```css
.box {
    background: cornflowerblue;
    height: 100px;
    width: 100px;
    transition-duration: 1s;
}
```

Now when we hover over the box, we can see it slowly move to the right and turn green. Smooth!

![box transition all](https://d2uusema5elisf.cloudfront.net/courses/fullstack-d3-masterclass/module_03/lesson_03.01/public/images/4-animations-and-transitions/css-transition-all.png)

Now let's say that we only want to animate our box's movement, but we want the color change to happen instantaneously. This is possible by specifying the `transition-property` CSS property. By default, `transition-property` is set to `all`, which animates all transitions. Instead, let's override the default and specify a specific CSS property name (`transform`).

We learn about CSS transitions and the different CSS transition properties, then run through a concrete example and look at how to debug them.
